R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 621
Example:
*RST; :CALC:TRAN:TIME:STAT?; :CALC:FILT:TIME:STAT?
Reset the instrument, activating a frequency sweep, and query whether the default
trace is displayed in the time domain and whether the time gate is enabled. The
response is 0;0.
CALCulate<Chn>:FILTer[:GATE]:TIME:STOP <numeric_value>
Defines the stop time of the time gate.
<Chn>
Channel number used to identify the active trace.
<numeric_value>
Stop time of the time gate
Range [def. unit]
–99.999999999998 s to +100 s. The increment (parameters UP or DOWN)
is 0.1 ns. [s]
*RST value
+4E-009 s
SCPI, Command
Types
Confirmed, command or query
Example:
See CALCulate<Chn>:FILTer[:GATE]:TIME:STARt.
Note: If the stop frequency entered is smaller than the current start frequency
(CALCulate<Chn>:FILTer[:GATE]:TIME:STARt), the start frequency is set to the stop frequency
minus the minimum frequency span (CALCulate<Chn>:FILTer[:GATE]:TIME:SPAN).
CALCulate<Chn>:FILTer[:GATE]:TIME[:TYPE] BPASs | NOTCh
Selects the time gate filter type, defining what occurs to the data in the specific time region.
<Chn>
Channel number used to identify the active trace.
Parameters
BPASs – bandpass filter: Pass all information in specified time region and
reject everything else.
NOTCh – notch filter: Reject all information in specified time region and pass
everything else.
*RST value
BPASs
SCPI, Command
Types
Confirmed, command or query
Example:
*RST; :CALC:FILT:TIME:STAT ON
Reset the instrument and enable the time gate.
CALC:FILT:TIME NOTCh
Select a notch filter in order to reject unwanted pulses.
