R&S ZVB - Page 635

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 620
CALCulate<Chn>:FILTer[:GATE]:TIME:SPAN <span>
Defines the span of the time gate.
<Chn>
Channel number used to identify the active trace.
<span>
Span of the time gate.
Range [def. unit]
2E-012 s to 200 s. The increment (parameters UP or DOWN) is 0.1 ns. [s]
*RST value
5E-009 s
SCPI, Command Types
Confirmed, command or query
Example:
See CALCulate<Chn>:FILTer[:GATE]:TIME:CENTer
CALCulate<Chn>:FILTer[:GATE]:TIME:STARt <start>
Defines the start time of the time gate.
<Chn>
Channel number used to identify the active trace.
<start>
Start time of the time gate
Range [def. unit]
–100 s to +99.999999999998 s. The increment (parameters UP or DOWN) is
0.1 ns. [s]
*RST value
–1E-009 s
SCPI, Command
Types
Confirmed, command or query
Example:
*RST; :CALC:TRAN:TIME:STAT ON; :CALC:FILT:TIME:STAT ON
Reset the instrument and enable the time domain representation and the
time gate.
CALC:FILT:TIME:STAR 0; STOP 10ns; SHOW ON
Set the start time to 0 ns and the stop time to 10 ns and display the time gate
permanently.
Note: If the start frequency entered is greater than the current stop frequency
(CALCulate<Chn>:FILTer[:GATE]:TIME:STOP), the stop frequency is set to the start frequency plus
the minimum frequency span (CALCulate<Chn>:FILTer[:GATE]:TIME:SPAN).
CALCulate<Chn>:FILTer[:GATE]:TIME:STATe <Boolean>
Determines whether the time gate for trace no. <Chn> is enabled.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON – time gate enabled
OFF – time gate disabled
*RST value
OFF [–]
SCPI,
Command
Types
Confirmed, command or query
