SCPI Command Reference
Operating Manual 1145.1084.12 – 30 619
Range [def. unit]
10 dB to 120 dB. The increment (parameters UP or DOWN) is 10 dB. [dB]
*RST value
32 dB
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; :CALC:FILT:TIME:WIND DCH
Reset the instrument and select a Dolph-Chebyshev time gate for filtering
the data in the frequency domain.
CALC:FILT:TIME:DCH 25
Set the sideband suppression to 25 dB.
CALCulate<Chn>:FILTer[:GATE]:TIME:SHAPe MAXimum | WIDE | NORMal |
MINimum
Selects the time gate to be applied to the time domain transform.
Use the generalized command CALCulate<Chn>:FILTer[:GATE]:TIME:WINDow if you wish to
select a Dolph-Chebychev time gate.
<Chn>
Channel number used to identify the active trace.
Parameters
MINimum – steepest edges (rectangle)
WIDE – normal gate (Hann)
NORM – steep edges (Hamming)
Maximum – maximum flatness (Bohman)
*RST value
WIDE
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; :CALC:FILT:TIME:SHAP?
Reset the instrument and query the type of time gate used. The response is
WIDE.
CALCulate<Chn>:FILTer[:GATE]:TIME:SHOW <Boolean>
Enables or disables permanent display of the gate limits.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON – time gate permanently displayed
OFF – time gate hidden
*RST value
OFF [–]
SCPI, Command Types
Device-specific, command or query
Example:
See CALCulate<Chn>:FILTer[:GATE]:TIME:CENTer
