R&S ZVB - Page 668

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 653
CALCulate<Chn>:MARKer<Mk>:MODE CONTinuous | DISCrete
Sets marker no. <Mk> to continuous or discrete mode. The marker doesn't have to be created before
(CALCulate<Chn>:MARKer<Mk>[:STATe] ON), the mode can be assigned in advance.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10
Parameters
CONTinuous – marker can be positioned on any point of the trace, and its
response values are obtained by interpolation.
DISCrete – marker can be set to discrete sweep points only.
*RST value
CONT
SCPI, Command
Types
Device-specific, command or quer.
Example:
Suppose that the active setup contains an active trace no. 1.
CALC:MARK:MODE DISC; :CALC:MARK2:MODE CONT
Create marker 1 in discrete mode and marker 2 in continuous mode.
CALC:MARK ON; MARK2 ON
Display the two markers. Due to the different modes the horizontal positions
can be different.
CALCulate<Chn>:MARKer<Mk>:NAME '<name>'
Defines a name for marker no. <Mk>. The marker doesn't have to be created before
(CALCulate<Chn>:MARKer<Mk>[:STATe] ON), the name can be assigned in advance.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10
'<name>'
Marker name (string parameter)
*RST value
'M 1' for marker no. 1 etc.
SCPI, Command Types
Device-specific, command or query
Example:
Suppose that the active setup contains an active trace no. 1.
CALC:MARK:NAME '&$% 1'; :CALC:MARK ON
Create marker 1 named &$% 1 and display the marker .
CALC:MARK:REF ON; :CALC:MARK:REF:NAME 'Reference'
Display the reference marker and rename it Reference.
CALCulate<Chn>:MARKer<Mk>:REFerence:MODE CONTinuous | DISCrete
Sets the reference marker to continuous or discrete mode. The marker doesn't have to be created before
(CALCulate<Chn>:MARKer<Mk>:REFerence[:STATe] ON), the mode can be assigned in advance.
