ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 679
 PHASe selects phase units (deg).
 GDELay selects time units (s).
 L selects inductance units (H/Henry).
 C selects capacitance units (F/Farad).
[–]
*RST value
–
SCPI, Command
Types
Device-specific, no query.
Example
*RST; :CALC:RIPP:DATA 1,1500000000, 2000000000,3
Define and enable a ripple limit range in the stimulus range between 1.5 GHz
and 2 GHz, assigning a ripple limit of +3 dB.
CALC:RIPP:RDOM:FORM COMP
Delete the ripple limit range, select complex units for the ripple limit.
CALCulate<Chn>:RIPPle:SEGMent<Seg>:COUNt?
Queries the number of ripple limit ranges.
<Chn>
Channel number used to identify the active trace.
<Seg>
Ripple limit range number. This suffix is ignored; the command counts all ranges.
Response
0 | 1 | ...- number of (enabled or disabled)) ripple limit ranges.
*RST value
0
SCPI,
Command
Types
Device-specific, query only.
Example:
*RST; :CALC:RIPP:DATA 1,1500000000, 2000000000, 3, 1, 2000000000, 3000000000, 5
Define and enable a ripple limit range in the stimulus range between 1.5 GHz and 2
GHz, assigning a ripple limit of +3 dB. Define and enable a second ripple limit range
in the stimulus range between 2 GHz and 3 GHz, assigning a ripple limit of +5 dB.
CALC:RIPP:SEGM:COUNT?
Query the number of ranges. The response is 2.
CALCulate<Chn>:RIPPle:SEGMent<Seg>:LIMit <limit_value>
Defines the ripple limit for ripple limit range no. <Seg>. A range must be created first to enable this
command (e.g CALCulate<Chn>:RIPPle:DATA).
To define several ripple limit ranges with a single command, use CALCulate<Chn>:RIPPle:DATA.
<Chn>
Channel number used to identify the active trace.
<Seg>
Segment number
