TLOG | PLIN | PLOG | PSINgle
Deletes the existing ripple limit ranges and (re-)defines the physical units of the stimulus values of the
ripple limit lines. The unit of the ripple limit is defined via CALCulate<Chn>:RIPPle:RDOMain:FORMat
<Chn>
Channel number used to identify the active trace.
Parameters
Keywords for the units of the stimulus values.
The selected unit must be compatible with the sweep type
([SENSe<Ch>:]SWEep:TYPE); otherwise the ripple limit lines cannot be
displayed and no ripple limit check is possible.
Range [def. unit]
The parameters form three groups:
 FLIN, FLOG, FSEG, and FSINgle select frequency units [default: Hz] for
the ripple limit.
 TLIN and TLOG select time units [default: s].
 PLIN, PLOG and PSINgle select power units [default: dBm].
*RST value
FLIN
SCPI,
Command
Types
Device-specific, no query.
Example:
SWE:TYPE POW
Select a power sweep.
CALC:RIPP:CONT:DOM PLIN
Delete all existing ripple limit ranges and select level units for the ripple limit of the
active trace.
CALC:RIPP:DATA 1, -10,-5,3
Define and enable a ripple limit range in the stimulus range between -10 dBm and
-5 dBm, assigning a ripple limit of 3 dB.
CALCulate<Chn>:RIPPle:DATA <type>, <start_stim>, <stop_stim>,
<limit>{,<type>, <start_stim>, <stop_stim>, <limit>}
Adds and enables/disables an arbitrary number of ripple limit ranges, assigning the stimulus values and
the ripple limits.
This command does not overwrite existing ripple limit ranges. The defined ranges are appended to
the range list as new ranges. Use the CALCulate<Chn>:RIPPle:SEGMent<Seg>... commands to
change existing ripple limits.
<Chn>
Channel number used to identify the active trace.
<type>
Boolean identifier for the type of the ripple limit range.
Range [def.
unit]
0 – ripple limit range off, range defined but no limit check result displayed. The
result is still available via CALCulate<Chn>:RIPPle:SEGMent<Seg>:RESult?
1 – ripple limit range on (with limit check)
<start_stim>,
<stop_stim>,
Stimulus values of the first and last points of the ripple limit range and associated
ripple limit. The unit of the ripple limit is adjusted to the format of the active trace
