SCPI Command Reference
Operating Manual 1145.1084.12 – 30 678
Define and enable a ripple limit range in the stimulus range between 1.5 GHz
and 2 GHz, assigning a ripple limit of +3 dB.
CALC:RIPP:DISP ON
Show the ripple limit range in the active diagram.
CALCulate<Chn>:RIPPle:FAIL?
Returns a 0 or 1 to indicate whether or not the global ripple limit check has failed.
Use CALCulate<Chn>:RIPPle:SEGMent<Seg>:RESult? to query the result for a single ripple
limit range.
In remote control, the ripple limit check result is calculated once at the end of each sweep. If the ripple
limits are changed, a new sweep is required to obtain updated ripple limit check results. In single sweep
mode (INITiate<Ch>:CONTinuous OFF), the new sweep must be started explicitly using
INITiate<Ch>[:IMMediate]:SCOPe ALL | SINGle. This behavior is different from manual control
where a changed ripple limit line can directly affect the pass/fail result of the displayed trace.
<Chn>
Channel number used to identify the active trace.
Response
0 | 1 - 0 represents pass (or a disabled limit check), 1 represents fail in at least
one ripple limit range.
*RST value
0
SCPI, Command
Types
Device-specific, query only.
Example:
*RST; :CALC:RIPP:DATA 1,1500000000, 2000000000,3
Define and enable a ripple limit range in the stimulus range between 1.5 GHz
and 2 GHz, assigning a ripple limit of +3 dB.
CALC:RIPP:STAT ON; FAIL?
Switch the limit check on and query the result.
CALCulate<Chn>:RIPPle:RDOMain:FORMat COMPlex | MAGNitude | PHASe |
REAL | IMAGinary | SWR | GDELay | L | C
Deletes the existing ripple limit ranges and (re-)defines the physical unit of the ripple limit. The units of the
stimulus values are defined via CALCulate<Chn>:RIPPle:CONTrol:DOMain.
<Chn>
Channel number used to identify the active trace.
Parameters
Keyword for the physical unit of the response values.
Range [def. unit]
The parameters form six groups:
 COMPlex, REAL, IMAGinary, and SWR select dimensionless numbers
(U) for the ripple limit.
 MAGNitude selects relative units (dB).
