ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 677
<limit>
(CALCulate<Chn>:FORMat).
Range [def.
unit]
Almost no restriction for ripple limit ranges; see Rules for Ripple Limit Definition.
[Hz for frequency sweeps, dBm for power sweeps, s for time sweeps, see
CALCulate<Chn>:RIPPle:CONTrol:DOMain]
*RST values
– (no ripple limit line defined after *RST)
SCPI,
Command
Types
Device-specific, with query.
Example:
*RST; :CALC:RIPP:DATA 1,1500000000, 2000000000, 3, 1, 2000000000, 3000000000, 5
Define and enable a ripple limit range in the stimulus range between 1.5 GHz and 2
GHz, assigning a ripple limit of +3 dB. Define and enable a second ripple limit
range in the stimulus range between 2 GHz and 3 GHz, assigning a ripple limit of
+5 dB.
CALC:RIPP:DISP ON
Show the ripple limits in the active diagram.
CALCulate<Chn>:RIPPle:DELete:ALL
Deletes all ripple limit ranges.
<Chn>
Channel number used to identify the active trace.
*RST value
–
SCPI,
Command
Types
Device-specific, no query.
Example:
*RST; :CALC:RIPP:DATA 1,1500000000, 2000000000, 3, 1, 2000000000, 3000000000, 5
Define and enable a ripple limit range in the stimulus range between 1.5 GHz and 2
GHz, assigning a ripple limit of +3 dB. Define and enable a second ripple limit range
in the stimulus range between 2 GHz and 3 GHz, assigning a ripple limit of +5 dB.
CALC:RIPP:DEL:ALL
Delete both created ripple limit ranges.
CALCulate<Chn>:RIPPle:DISPlay[:STATe] <Boolean>
Displays or hides all ripple limit lines (including all ranges) associated to the active trace.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON | OFF - ripple limit line on or off.
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query.
Example:
*RST; :CALC:RIPP:DATA 1,1500000000, 2000000000, 3
