ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 700
CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<Log_pt>:PAR
ameters:R<no> STSL | STSC | SLST | SCST | CSSL | LSSC | CSSC | LSSL | SLCS |
SCLS | SCCS | SLLS,<numeric_value>
Specifies the resistance values R1, R2, R3 in the different circuit models for balanced port deembedding.
<Ch>
Channel number
<Log_pt>
Logical port number (balanced port)
<no>
Number of resistance in circuit model. If unspecified the numeric suffix is set to
1.
Range [def. unit]
1 to 3 [–] The number of resistances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Resistance R<no> for the specified circuit model.
Range [def. unit]
–10 MΩ to 10 MΩ [Ω]. The increment is 1 mΩ (10
–3
Ω).
*RST value
0 Ω for all resistances connected in series with an inductance
10 MΩ for all resistances connected in parallel with a capacitance
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the resistance value for the
specified circuit model.
Example:
*RST; :SOUR:LPOR1 1,2; :CALC:TRAN:VNET:BAL:DEEM:PAR:R1? CSSL; R2? CSSL;
R3? CSSL
Create a balanced port and query the default resistances for the Serial Cs,
shunt L circuit model. The response is 10000000000;10000000000; 0.
CALC:TRAN:VNET:BAL:DEEM:PAR:R3 CSSL, 2.2E+3
Increase the resistance R3 to 2.2 kΩ.
CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<Log_pt>[:STA
Te] <Boolean>
Enables or disables the deembedding function for balanced ports. It is allowed to change the circuit model
and its parameters while deembedding is enabled.
<Ch>
Channel number
<Log_pt>
Logical port number (balanced port)
<Boolean>
ON – Deembedding active
OFF – Deembedding inactive
*RST value
OFF [–]
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; SOUR:LPOR1 1,2; LPOR2 3,4
Define a balanced port configuration.
CALC:TRAN:VNET:BAL:DEEM:TND CSSL
