ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 701
Select the Serial Cs, shunt L circuit model for deembedding.
CALC:TRAN:VNET:BAL:DEEM:PAR:R3 CSSL, 2.2E+3; :CALC:TRAN:VNET:BAL:DEEM ON
Increase the resistance R3 for the Serial Cs, shunt L circuit model to 2.2 kΩ
and enable deembedding.
CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<Log_pt>:TND
efinition FIMPort | STSL | STSC | SLST | SCST | CSSL | LSSC | CSSC | LSSL | SLCS
| SCLS | SCCS | SLLS
Selects the circuit model for balanced port deembedding.
<Ch>
Channel number
<Log_pt>
Logical port number (balanced port)
Parameters
Possible circuit models (character data); see circuit models.
*RST value
CSSL
SCPI, Command Types
Device-specific, command or query.
Example:
See CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding[:STATe]
CALCulate<Ch>:TRANsform:VNETworks:BALanced:EMBedding<Log_pt>:PARam
eters:C<no> STSC | SCST | CSSL | LSSC | CSSC | SLCS | SCLS |
SCCS,<numeric_value>
Specifies the capacitance values C1, C2, C3 in the different circuit models for balanced port embedding.
<Ch>
Channel number
<Log_pt>
Logical port number (balanced port)
<no>
Number of capacitance in circuit model. If unspecified the numeric suffix is set
to 1.
Range [def. unit]
1 to 3 [–] The number of capacitances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Capacitance C<no> for the specified circuit model.
Range [def. unit]
–1mF to 1 mF [F]. The increment is 1 fF (10
–15
F).
*RST value
1 pF (10
–12
F)
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the capacitance value for
the specified circuit model.
Example:
*RST; :SOUR:LPOR1 1,2; :CALC:TRAN:VNET:BAL:EMB:PAR:C2? CSSL
Create a balanced port and query the default capacitance C2 for the Serial Cs,
shunt L circuit model. The response is 1E-012 (1 pF).
