CALC:TRAN:VNET:BAL:EMB:PAR:C2 CSSL, 2.2E-12
Increase the capacitance to 2.2 pF.
CALCulate<Ch>:TRANsform:VNETworks:BALanced:EMBedding<Log_pt>:PARam
eters:L<no> STSL | SLST | CSSL | LSSC | LSSL | SLCS | SCLS |
SLLS,<numeric_value>
Specifies the inductance values L1, L2, L3 in the different circuit models for balanced port embedding.
<Ch>
Channel number
<Log_pt>
Logical port number (balanced port)
<no>
Number of inductance in circuit model. If unspecified the numeric suffix is set
to 1.
Range [def. unit]
1 to 3 [–] The number of inductances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Inductance L<no> for the specified circuit model.
Range [def. unit]
–1H to 1 H [H]. The increment is 1 pH (10
–12
H).
*RST value
1 nH (10
–9
H)
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the inductance value for the
specified circuit model.
Example:
*RST; :SOUR:LPOR1 1,2; :CALC:TRAN:VNET:BAL:EMB:PAR:L1? CSSL
Create a balanced port and query the default inductance L1 for the Serial Cs,
shunt L circuit model. The response is 1E-009 (1 nH).
CALC:TRAN:VNET:BAL:EMB:PAR:L1 CSSL, 2.2E-9
Increase the inductance to 2.2 nH.
CALCulate<Ch>:TRANsform:VNETworks:BALanced:EMBedding<Log_pt>:PARam
eters:R<no> STSL | STSC | SLST | SCST | CSSL | LSSC | CSSC | LSSL | SLCS |
SCLS | SCCS | SLLS,<numeric_value>
Specifies the resistance values R1, R2, R3 in the different circuit models for balanced port embedding.
<Ch>
Channel number
<Log_pt>
Logical port number (balanced port)
<no>
Number of resistance in circuit model. If unspecified the numeric suffix is set to
1.
Range [def. unit]
1 to 3 [–] The number of resistances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
