Example:
*RST; :CALC:TRAN:VNET:PPA:DEEM:DEF 1,2;
CALC:TRAN:VNET:PPA:DEEM:PAR:R1? CSSL; R2? CSSL; R3? CSSL
Create a list of port pairs and query the default resistances for the Serial Cs,
shunt L circuit model. The response is 10000000000;10000000000; 0.
CALC:TRAN:VNET:PPA:DEEM:PAR:R3 CSSL, 2.2E+3
Increase the resistance R3 to 2.2 kΩ.
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<List_idx>[:STATe]
<Boolean>
Enables or disables the deembedding function for port pairs. It is allowed to change the circuit model and
its parameters while deembedding is enabled.
<Ch>
Channel number
<List_idx>
Current number of a port pair in the list, defined via
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<List_idx>:DE
Fine
<Boolean>
ON – Deembedding active
OFF – Deembedding inactive
*RST value
OFF [–]
SCPI,
Command
Types
Device-specific, command or query
Example:
*RST; :CALC:TRAN:VNET:PPA:DEEM:DEF 1,2,3,4
Define a port pair configuration with two port pairs.
CALC:TRAN:VNET:PPA:DEEM1:TND CSSL
Select the Serial Cs, shunt L circuit model for the first port pair.
CALC:TRAN:VNET:PPA:DEEM:PAR:R3 CSSL, 2.2E+3; :CALC:TRAN:VNET:PPA:DEEM ON
Increase the resistance R3 for the Serial Cs, shunt L circuit model to 2.2 kΩ and enable
deembedding.
...
CALC:TRAN:VNET:PPA:DEEM:DEL
Delete the port pair configuration.
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<List_idx>:TNDefini
tion FIMPort | STSL | STSC | SLST | SCST | CSSL | LSSC | CSSC | LSSL | SLCS |
SCLS | SCCS | SLLS
Selects the circuit model for port pair deembedding.
<Ch>
Channel number
<List_idx>
Current number of a port pair in the list, defined via
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<List_idx>:DE
