ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 710
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<List_id
x>:DEFine
<no>
Number of inductance in circuit model. If unspecified the numeric suffix is set to
1.
Range [def. unit]
1 to 3 [–] The number of inductances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Inductance L<no> for the specified circuit model.
Range [def. unit]
–1H to 1 H [H]. The increment is 1 pH (10
–12
H).
*RST value
1 nH (10
–9
H)
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the inductance value for the
specified circuit model.
Example:
*RST; :CALC:TRAN:VNET:PPA:DEEM:DEF 1,2; :CALC:TRAN:VNET:PPA:DEEM:PAR:L1?
CSSL
Create a list of port pairs and query the default inductance L1 for the Serial Cs,
shunt L circuit model. The response is 1E-009 (1 nH).
CALC:TRAN:VNET:PPA:DEEM:PAR:L1 CSSL, 2.2E-9
Increase the inductance to 2.2 nH.
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<List_idx>:PARame
ters:R<no> STSL | STSC | SLST | SCST | CSSL | LSSC | CSSC | LSSL | SLCS |
SCLS | SCCS | SLLS,<numeric_value>
Specifies the resistance values R1, R2, R3 in the different circuit models for port pair deembedding.
<Ch>
Channel number
<List_idx>
Current number of a port pair in the list, defined via
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<List_id
x>:DEFine
<no>
Number of resistance in circuit model. If unspecified the numeric suffix is set to
1.
Range [def. unit]
1 to 3 [–] The number of resistances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Resistance R<no> for the specified circuit model.
Range [def. unit]
–10 MΩ to 10 MΩ [Ω]. The increment is 1 mΩ (10
–3
Ω).
*RST value
0 Ω for all resistances connected in series with an inductance
10 MΩ for all resistances connected in parallel with a capacitance
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the resistance value for the
specified circuit model.
