R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 718
<Boolean>
ON – Deembedding active
OFF – Deembedding inactive
*RST value
OFF [–]
SCPI, Command
Types
Device-specific, command or query
Example:
CALC:TRAN:VNET:SEND:DEEM:TND CSL
Select the Serial C, shunt L circuit model for deembedding.
CALC:TRAN:VNET:SEND:DEEM:PAR:R2 CSL, 2.2E+3; :CALC:TRAN:VNET:SEND:DEEM
ON
Increase the resistance R2 for the Serial C, shunt L circuit model to 2.2 kΩ and
enable deembedding.
CALCulate<Ch>:TRANsform:VNETworks:SENDed:DEEMbedding<Ph_pt>:TNDefini
tion FIMPort | CSL | LSC | CSC | LSL | SLC | SCL | SCC | SLL
Selects the circuit model for single ended port deembedding.
<Ch>
Channel number.
<Ph_pt>
Physical port number
Parameters
Possible circuit models (character data); see circuit models.
*RST value
CSL
SCPI, Command Types
Device-specific, command or query.
Example:
See CALCulate<Ch>:TRANsform:VNETworks:SENDed:DEEMbedding[:STATe]
CALCulate<Ch>:TRANsform:VNETworks:SENDed:EMBedding<Ph_pt>:PARameter
s:C<no> CSL | LSC | CSC | SLC | SCL | SCC,<numeric_value>
Specifies the capacitance values C1, C2 in the different circuit models for single ended port embedding.
<Ch>
Channel number.
<Ph_pt>
Physical port number
<no>
Number of capacitance in circuit model. If unspecified the numeric suffix is set
to 1.
Range [def. unit]
1 to 2 [–] The number of capacitances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Capacitance C<no> for the specified circuit model.
Range [def. unit]
–1mF to 1 mF [F]. The increment is 1 fF (10
–15
F).
*RST value
1 pF (10
–12
F)
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the capacitance value for
