the specified circuit model.
Example:
*RST; :CALC:TRAN:VNET:SEND:EMB:PAR:C2? CSC
Query the default capacitance C2 for the Serial C, shunt C circuit model. The
response is 1E-012 (1 pF).
CALC:TRAN:VNET:SEND:EMB:PAR:C2 CSC, 2.2E-12
Increase the capacitance to 2.2 pF.
CALCulate<Ch>:TRANsform:VNETworks:SENDed:EMBedding<Ph_pt>:PARameter
s:L<no> CSL | LSC | LSL | SLC | SCL | SLL,<numeric_value>
Specifies the inductance values L1, L2 in the different circuit models for single ended port embedding.
<Ch>
Channel number.
<Ph_pt>
Physical port number
<no>
Number of inductance in circuit model. If unspecified the numeric suffix is set
to 1.
Range [def. unit]
1 to 2 [–] The number of inductances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Inductance L<no> for the specified circuit model.
Range [def. unit]
–1H to 1 H [H]. The increment is 1 pH (10
–12
H).
*RST value
1 nH (10
–9
H)
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the inductance value for the
specified circuit model.
Example:
*RST; :CALC:TRAN:VNET:SEND:EMB:PAR:L1? SLL
Query the default inductance L1 for the Shunt L, serial L circuit model. The
response is 1E-009 (1 nH).
CALC:TRAN:VNET:SEND:EMB:PAR:L1 SLL, 2.2E-9
Increase the inductance to 2.2 nH.
CALCulate<Ch>:TRANsform:VNETworks:SENDed:EMBedding<Ph_pt>:PARameter
s:R<no> CSL | LSC | CSC | LSL | SLC | SCL | SCC | SLL,<numeric_value>
Specifies the resistance values R1, R2 in the different circuit models for single ended port embedding.
<Ch>
Channel number.
<Ph_pt>
Physical port number
<no>
Number of resistance in circuit model. If unspecified the numeric suffix is set to
1.
