R&S ZVB - Page 735

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 720
Range [def. unit]
1 to 2 [–] The number of resistances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
<numeric_value>
Resistance R<no> for the specified circuit model.
Range [def. unit]
–10 MΩ to 10 MΩ [Ω]. The increment is 1 mΩ (10
–3
Ω).
*RST value
0 Ω for all resistances connected in series with an inductance
10 MΩ for all resistances connected in parallel with a capacitance
SCPI, Command
Types
Device-specific, command or query. In the query form, the <numeric_value>
parameter must be omitted. The command returns the resistance value for the
specified circuit model.
Example:
*RST; :CALC:TRAN:VNET:SEND:EMB:PAR:R1? CSL; R2? CSL
Query the default resistances for the Serial C, shunt L circuit model. The
response is 10000000; 0.
CALC:TRAN:VNET:SEND:EMB:PAR:R2 CSL, 2.2E+3
Increase the resistance R2 to 2.2 kΩ.
CALCulate<Ch>:TRANsform:VNETworks:SENDed:EMBedding<Ph_pt>[:STATe]
<Boolean>
Enables or disables the embedding function for single ended ports. It is allowed to change the circuit
model and its parameters while embedding is enabled.
<Ch>
Channel number.
<Ph_pt>
Physical port number
<Boolean>
ON – Embedding active
OFF – Embedding inactive
*RST value
OFF [–]
SCPI, Command
Types
Device-specific, command or query
Example:
CALC:TRAN:VNET:SEND:EMB:TND CSL
Select the Serial C, shunt L circuit model for embedding.
CALC:TRAN:VNET:SEND:EMB:PAR:R2 CSL, 2.2E+3; :CALC:TRAN:VNET:SEND:EMB ON
Increase the resistance R2 for the Serial C, shunt L circuit model to 2.2 kΩ
and enable embedding.
CALCulate<Ch>:TRANsform:VNETworks:SENDed:EMBedding<Ph_pt>:TNDefinitio
n FIMPort | CSL | LSC | CSC | LSL | SLC | SCL | SCC | SLL
Selects the circuit model for single ended port embedding.
<Ch>
Channel number.
