R&S ZVB - Page 744

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 729
CONTrol:HANDler:RESet to restore default values.
SCPI, Command
Types
Device-specific, command or query
Example:
See CONTrol:HANDler:A[:DATA]
CONTrol:HANDler[:EXTension]:INDex:STATe <Boolean>
Selects the digital signal that is routed to pin 20 of the Universal Interface connector.
<Boolean>
ON – /INDEX signal at pin 20
OFF – /PORT_B6 signal at pin 20
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Note: *RST does not change the configuration of the Universal Interface. Use
CONTrol:HANDler:RESet to restore default values.
Example:
CONT:HAND:EXT:IND:STAT ON
Route the /INDEX signal to pin 20.
CONT:HAND:EXT:RTR:STAT ON
Route the /READY_FOR_TRIGGER signal to pin 21.
CONT:HAND:RES
Restore the default state: Pins no. 20 and 21 are available for port B input/output
signals.
CONTrol:HANDler[:EXTension]:RTRigger:STATe
Selects the digital signal that is routed to pin 21 of the Universal Interface connector.
<Boolean>
ON – /READY_FOR_TRIGGER
OFF – /PORT_B7 signal at pin 21
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Note: *RST does not change the configuration of the Universal Interface. Use
CONTrol:HANDler:RESet to restore default values.
Example:
See CONTrol:HANDler[:EXTension]:INDex:STATe
CONTrol:HANDler:OUTPut<port>[:DATA] <binary>
Writes a 0 or 1 to the output ports (pin 3 or 4) of the Universal Interface connector. The port lines have
negative logic: A "0" corresponds to a high signal, a "1" to a low signal.
The query reads the last value that has been written to the output port.
<port>
Output port number:
