ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 730
1 – /OUTPUT1 (pin 3)
2 – /OUTPUT2 (pin 4)
<binary>
0 – high
1 – low
The parameters MIN, MAX, DEF are not supported.
*RST value
0
SCPI,
Command
Types
Device-specific, command or query
Note: *RST does not change the configuration of the Universal Interface. Use
CONTrol:HANDler:RESet to restore default values.
Example:
CONT:HAND:OUTP2:DATA 0
Set the /OUTPUT2 line (pin 4) to 0 (current state of /OUTPUT2).
CONT:HAND:OUTP2:USER 1
Define the next state of the /OUTPUT2 line as 1 (low). /OUTPUT2 will go from 0 to
1 when the analyzer receives a negative pulse on the /INPUT1 line (pin 2).
CONTrol:HANDler:OUTPut<port>:USER <binary>
Defines the state of the output ports (pin 3 or 4) of the Universal Interface connector after the next
negative pulse on the /INPUT1 line (pin 2).
<port>
Output port number:
1 – /OUTPUT1 (pin 3)
2 – /OUTPUT2 (pin 4)
<binary>
0 – high
1 – low
The parameters MIN, MAX, DEF are not supported.
*RST value
0
SCPI, Command
Types
Device-specific, command or query
Note: *RST does not change the configuration of the Universal Interface. Use
CONTrol:HANDler:RESet to restore default values.
Example:
See CONTrol:HANDler:OUTPut<port>[:DATA]
CONTrol:HANDler:RESet
Restores the default states of the CONTrol:HANDler... commands including the data port values.
*RST value
n/a
SCPI, Command Types
Device-specific, no query (event)
Example:
See CONTrol:HANDler[:EXTension]:INDex:STATe
