R&S ZVB - Page 748

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 733
DIAGnostic:ALC:PIParameter:GAIN <prop_gain>
[Deprecated command, replaced by SOURce<Ch>:POWer<Pt>:ALC:PIParameter:GAIN]
Defines the proportional gain of the PI controller. This setting takes effect when manual setting of the
controller parameters is enabled (DIAGnostic:ALC:PIParameter MANual).
<prop_gain>
Proportional gain setting
Range [def. unit]
0.001 to 100 [1]. UP and DOWN increment the proportional gain in 0.001
steps.
*RST value
0.4
SCPI, Command
Types
Device-specific, command or query.
Example:
See DIAGnostic:ALC:SETTings:AUBW
DIAGnostic:ALC:PIParameter:ITIMe <int_time>
[Deprecated command, replaced by SOURce<Ch>:POWer<Pt>:ALC:PIParameter:ITIMe]
Defines the integration time of the PI controller. This setting takes effect when manual setting of the
controller parameters is enabled (DIAGnostic:ALC:PIParameter MANual).
<prop_gain>
Integration time setting
Range [def. unit]
10 ns to 100 s [s]. UP and DOWN increment the integration time in 10 ns
steps.
*RST value
500 ns
SCPI, Command
Types
Device-specific, command or query.
Example:
See DIAGnostic:ALC:SETTings:AUBW
DIAGnostic:ALC:POFFset <Boolean>
[Deprecated command, replaced by SOURce<Ch>:POWer<Pt>:ALC:POFFset]
Causes the analyzer to use the ALC of the previous measurement as an ALC start offset value (Use ALC
Offset of Prev. Measurement).
<Boolean>
ON | OFF -Use ALC Offset... on or off.
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
Example:
See DIAGnostic:ALC:SETTings:AUBW
DIAGnostic:ALC:RANGe <cont_range>
[Deprecated command, replaced by SOURce<Ch>:POWer<Pt>:ALC:RANGe]
