R&S ZVB - Page 836

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 821
Parameter
Meaning
Comment/Unit
<Z0>
Reference impedance (no unit)
To be specified
without unit (implicit
unit is Ω)
<C0> | <L0>
Polynomial coefficients C
0
or L
0
for the fringing capacitance or residual inductance of the
standard (load parameter)
To be specified
without unit (implicit
unit is fF or pH)
<C1> | <L1>
Polynomial coefficients C
1
or L
1
for the fringing capacitance or residual inductance of the
standard (load parameter)
To be specified
without unit (implicit
unit is fF /GHz or
pH /GHz)
<C2> | <L2>
Polynomial coefficients C
2
or L
2
for the fringing capacitance or residual inductance of the
standard (load parameter)
To be specified
without unit (implicit
unit is fF/GHz
2
or
pH/GHz
2
)
<C3> | <L3>
Polynomial coefficients C
3
or L
3
for the fringing capacitance or residual inductance of the
standard (load parameter)
To be specified
without unit (implicit
unit is fF/GHz
3
or
pH/GHz
3
)
OPEN | SHORt |
MATCh |
<Resistance>
Modelling as an Open, Short or Match standard or as a Resistance.
The load circuit for Open, Short and Match consists of capacitance C which is
connected in parallel to an inductance L and a resistance R, both connected in series.
OPEN means that R is infinite so that the standard behaves like a capacitor (no
inductance, the polynomial coefficients specify C). SHORt means that R is zero so that
the standard behaves like an inductance (no capacitance, the polynomial coefficients
specify L). MATCh means that the standard behaves like a perfect 50 Ω match.
Character data
, <Port_1>,
<Port_2>
Optional port restriction: one port number for one port standards, two port numbers for
two port standards
Integer value
The different standard types are defined by the following parameters. Port restrictions are indicated in
brackets:
<std_type>
Meaning
Parameters in
[SENSe<Ch>:]CORRection:CKIT:<conn_type>:<std_type>
MOPen | FOPen
MOPen(P1) | FOPen(P2) ...
Open (m) or open (f)
Open (m or f with port
restriction)...
'<Ckit_Name>' ... <C3>[, <Port_1>]
complete parameter list with capacitance coefficients, no OPEN |
SHORT | MATCh
MSHort | FSHort
Short (m) or short (f)
'<Ckit_Name>' ... <L3>[, <Port_1>]
complete parameter list with inductance coefficients, no OPEN |
SHORT| MATCh
OSHort | MOSHort |
MOSHORT1 | MOSHORT2 |
MOSHORT3 | FOSHort |
FOSHORT1 | FOSHORT2 |
FOSHORT3
(MOSHort and MOSHORT1
etc. are equivalent)
Offset short (sexless) or
offset short (m) or offset
short (f)
(for user-defined
connector types only)
'<Ckit_Name>' ... <L3>[, <Port_1>]
complete parameter list with inductance coefficients, no OPEN |
SHORT| MATCh
MMTCh | FMTCh
Match (m) or match (f)
'<Ckit_Name>' ... <Max_Freq>[, <Port_1>]
no offset parameters, no load parameters (polynomial coefficients), no
