ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 820
N50, N75: N 50 Ω or N 75 Ω connectors
PC7, PC35, PC292: PC 7, PC 3.5 or 2.92 mm connectors
SMA: User-defined connector type SMA...
USER<no>: User-defined connectors UserConn1, UserConn2
Note: This command supports ZVR-compatible connector types only. For general
definitions use [SENSe<Ch>:]CORRection:CKIT:<std_type>.
<std_type>
Standard type. For reflection standards, the first character denotes the gender, e.g.:
FOPEN, MOPEN: Open (f) or Open (m) standard.
For transmission standards, the first two characters denotes the genders on both
ends, e.g.:
FFTHrough, MFTHrough, MMTHrough: Through (ff), Through (mf) or Through
(mm) standard.
For a complete list of standard types refer to the table of standard types.
Parameter list
String parameters to specify the configured standard ('<Ckit_Name>','<Std_No>')
and numeric parameters defining its properties. See detailed description below.
*RST value
–
SCPI,
Command
Types
Device-specific, command or query
Example:
CORR:CKIT:N50:FOPEN 'ZV-Z21','',0,1.8E+010,0.0151,0,0,0.22,-0.22,0.0022
Define the properties of the open (f) standard for the N 50 Ω connector type
contained in the ZV-Z21 calibration kit: Assign a valid frequency range of 0 Hz to 18
GHz, an electrical length of 15.1 mm, 0 dB loss and define the polynomial
coefficients of the fringing capacitance as 0 fF, 0.22 fF/GHz, –0.22 fF/(GHz)
2
,
0.0022 fF/(GHz)
3
.
The parameters in the [SENSe<Ch>:]CORRection:CKIT:<std_type> and
[SENSe<Ch>:]CORRection:CKIT:<conn_type>:<std_type> commands have the following
meaning:
Parameter
Meaning
Comment/Unit
'<Conn_Name>'
Name of the connector type. Use SENSe1:CORRection:CONNection:CATalog? to
query connector names.
String parameter
'<Ckit_Name>'
Name of the calibration kit. Use [SENSe<Ch>:]CORRection:CKIT:CATalog? to
query cal kit names.
String parameter
'<Std_No>'
Label (e.g. the serial number) of the standard
String parameter
<Min_Freq>
Min. frequency for which the circuit model is valid
Default unit is Hz
<Max_Freq>
Max. frequency for which the circuit model is valid
Default unit is Hz
<El_Length>
Electrical length (offset parameter) of the standard
Default unit is m
<Loss>
Loss (offset parameter) of the standard
To be specified
without unit (implicit
unit is dB)
