<conn_type>
Connector type, one of the following identifiers:
N50, N75: N 50 Ω or N 75 Ω connectors
PC7, PC35, PC292: PC 7, PC 3.5 or 2.92 mm connectors
SMA: Connector type SMA
USER<no>: User-defined connectors UserConn1, UserConn2
'<ckit_name>'
String parameter containing the name of a calibration kit available on the
analyzer.
*RST value
– (A *RST does not change the assignment between connector types and
calibration kits.)
SCPI, Command
Types
Device-specific, command or query
Example:
MMEM:LOAD:CKIT 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\Calibration\Kits\New_kit.calkit'
Load the previously created cal kit file New_kit.calkit
from the default cal kit directory.
CORR:CKIT:N50:SEL 'New_kit'
Assign the imported kit to the N 50 Ω connector type (assuming that the cal kit
name stored in New_kit.calkit reads New_kit).
Cal kit naming conventions
Calibration kit names must be entered as string parameters. The string contains the cal kit name used in
the Calibration Kits dialog; a Ω in the name must be replaced by 'Ohm', e.g.:
 'NewKit1' denotes the user-defined calibration kit NewKit1.
 'N 50 Ohm Ideal Kit' denotes the N 50 Ω Ideal Kit.
 'ZV-Z21 typical' denotes the cal kit ZV-Z21 typical.
[SENSe<Ch>:]CORRection:CKIT:<conn_type>:<std_type>
'<Ckit_Name>','<Std_No>',<Min_Freq>,<Max_Freq>,<El_Length>,<Loss>,<C0> |
<L0>,<C1> | <L1>,<C2> | <L2>,<C3> | <L3>, OPEN | SHORt
[Deprecated command, replaced by [SENSe<Ch>:]CORRection:CKIT:<std_type>]
Defines the parameters of a calibration standard <std_type> for a specified connector type <conn_type>.
A particular physical standard can be selected by specifying the name of the calibration kit and its serial
number.
It is not possible to modify predefined or ideal kits. If the specified cal kit does not exist, it is created with
the specified calibration standard.
The result is undefined if multiple calibration kits with the same name but different labels exist.
Depending on the standard type, only a subset of the parameters may be used; refer to the table of
standard types.
<Ch>
Channel number. This suffix is ignored because calibration kits are channel-
independent.
<conn_type>
Connector type, one of the following identifiers:
