ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 826
For a complete list of standard types refer to the table of standard types.
Parameter
list
String parameters to specify the configured standard
('<Conn_Name>','<Ckit_Name>','<Std_No>') and numeric parameters
defining its properties. See detailed description.
Note: The following transmission standards have only 8 parameters (until <Z0>):
MMTHrough, MFTHrough, FFTHrough, MMLine, MFLine, FFLine
The following reflection and transmission standards have only 5 parameters (until
<Max_Freq>):
MSMatch, FSMatch, MMATten, MFATten, FFATten
*RST value
–
SCPI,
Command
Types
Device-specific, command or query (see examples below)
Example:
CORR:CKIT:FOP 'N 50 Ohm','Test Kit',...
Define the properties of the Open (f) standard for a N 50 Ω connector type in cal kit
'Test Kit'. See also example for
[SENSe<Ch>:]CORRection:CKIT:<conn_type>:<std_type>.
CORR:CKIT:FOP? 'N 50 Ohm'
Query the properties of the open (f) standard for a N 50 Ω connector type in the
active cal kit.
CORR:CKIT:FOP? 'N 50 Ohm','Test Kit'
Query the properties of the Open (f) standard for a N 50 Ω connector type in cal kit
'Test Kit'.
[SENSe<Ch>:]CORRection:CKIT... with Labels
The following [SENSe:]CORRection:CKIT... commands identify the calibration kit to be used by a
combination of its <CalkitName> and <CalkitLabel>. Typically, the serial number of the calibration kit
serves as a calibration kit label. Due to their different labels, the analyzer can handle several calibration
kits with identical names.
If multiple calibration kits with the same name and different labels exist, the behavior of certain legacy
[SENSe<Ch>:]CORRection:CKIT commands without label is undefined.
[SENSe<Ch>:]CORRection:CKIT:<conn_type>:LSELect '<ckit_name>',
'<ckit_label>'
Selects the calibration kit to be used for a specified connector type <conn_type>. The kit is identified by its
name and label.
For connector types with arbitrary, user-defined names and labels you can use the command
[SENSe<Ch>:]CORRection:CKIT:LSELect '<conn_name>', '<ckit_name>', <ckit_label>'.
<Ch>
Channel number. This suffix is ignored because calibration kits are channel-
independent.
<conn_type>
Connector type, one of the following identifiers:
