R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 818
Calibration type
Parameters in
[SENSe<Ch>:]CORRection:COLLect:METHod:DEFine
Available error terms (depending on
port numbers)
Two-port
normalization
FRTRans
'TRANSTRACK'
One path two port
OPTPort
'DIRECTIVITY', 'SRCMATCH',
'REFLTRACK', 'TRANSTRACK'
TOSM
TOSM
'DIRECTIVITY', 'SRCMATCH',
'REFLTRACK', 'LOADMATCH',
'TRANSTRACK'
TOM, TRM, TRL,
TNA
TOM | TRM | TRL | TNA
'DIRECTIVITY', 'SRCMATCH',
'REFLTRACK', 'LOADMATCH',
'TRANSTRACK' (for reading and writing)
'G11' ... 'G22' and 'H11', 'H12', 'H22' (for
reading only; the 'H21' matrix elements
are normalized to 1)
[SENSe<Ch>:]CORRection:CKIT...
The [SENSe:]CORRection:CKIT... commands deal with calibration kits and cal kit data. The
calibration kits are distinguished by their names (<CalkitName>), the optional labels (<label>) can be used
to carry information about the calibration standard.
In order to handle several identical calibration kits with different serial numbers use the commands of
section [SENSe<Ch>:]CORRection:CKIT... with Labels.
[SENSe<Ch>:]CORRection:CKIT:CATalog? '<conn_name>'
Returns a list of all cal kits for a given connector type. The kit is identified by its name.
The result is undefined if multiple calibration kits with the same name but different labels exist.
<Ch>
Channel number. This suffix is ignored because cal kits are channel-
independent.
<conn_name>
Name of the connector type. Use
SENSe1:CORRection:CONNection:CATalog? to query connector names.
*RST value
–
SCPI, Command
Types
Device-specific, query only
Example:
See SENSe<Ch>:CORRection:CONNection:CATalog?
[SENSe<Ch>:]CORRection:CKIT:<conn_type>:SELect '<ckit_name>'
Selects the calibration kit to be used for a ZVR-compatible connector type <conn_type>.
For connector types with arbitrary, user-defined names you can use the command
[SENSe<Ch>:]CORRection:CKIT:SELect'<conn_name>', '<ckit_name>' .
The result is undefined if multiple calibration kits with the same name but different labels exist.
<Ch>
Channel number. This suffix is ignored because calibration kits are channel-
independent.
