ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 831
[SENSe<Ch>:]CORRection:COLLect[:ACQuire] THRough | OPEN1 | OPEN2 |
OPEN12 | SHORT1 | SHORT2 | SHORT12 | MATCH1 | MATCH2 | MATCH12 | NET |
ATT | IMATCH12 | REFL1 | REFL2 | SLIDE1 | SLIDE2 | SLIDE12 | LINE1 | LINE2 |
LINE3 | M1O2 | O1M2 | M1S2 | S1M2 | OSHORT1 | OSHORT11 | OSHORT12 |
OSHORT13 | OSHORT2 | OSHORT21 | OSHORT22 | OSHORT23 | UTHRough |
ISOLation [, <Dispersion>, AUTO | <delay | phase>]
[Deprecated command]
Starts a calibration measurement in order to acquire measurement data for the selected standards. The
standards are reflection or transmission standards and must be connected to port 1 or 2 of the analyzer.
Use the generalized command [SENSe<Ch>:]CORRection:COLLect[:ACQuire]:SELected to
obtain measurement data at arbitrary analyzer ports.
<Ch>
Channel number
THRough ...
UTHRough
Standard types: Through (between port 1 and 2), Open, Short, Match (MATCH12
and IMATCH12 are synonymous), Symmetric Network (NET), Attenuation (ATT),
Reflect, Sliding Match (SLIDe), Line1 (LINE1 and LINE are synonymous), Line2 and
Line3 (esp. for TRL calibration), Match/Open (M1O2, O1M2), Match/Short (M1S2,
S1M2), Offset Short (OSHORT), Unknown Through (UTHRough), Isolation
(optional, between port 1 and 2).
The numbers in the parameter names denote the analyzer ports. Two numbers 12
mean that two separate calibrations are performed at ports 1 and 2. For Offset Short
standards, the first number denotes the port (1 or 2), the second number denotes
the number of the standard (1 to 3).
*RST value
ON
<Dispersion>
Optional status parameter for UTHRough standard:
OFF – Unknown through standard is non-dispersive
ON – Unknown through standard is dispersive
*RST value
OFF
AUTO |
<delay |
phase>
Optional entry of delay time or phase for UTHRough standard:
AUTO – The analyzer determines the delay time or phase during the calibration
sweep
<delay or phase> – entry of the delay time in ps (for non-dispersive standards) or of
an estimate of the phase at the start frequency of the sweep in deg (for dispersive
standards).
See also background information for
[SENSe<Ch>:]CORRection:COLLect[:ACQuire]:SELected.
*RST value
AUTO
SCPI,
Command
Types
Confirmed (with device-specific standards), no query
Example:
See [SENSe<Ch>:]CORRection:COLLect:SAVE.
