, <C1>, <C2>, <C3>, <L0>, <L1>, <L2>, <L3>[[, OPEN | SHORt | MATCh |
<Resistance>], <Port_1>, <Port_2>]
Defines the parameters of a non-ideal 1 port or 2-port calibration standard <std_type>. A particular
physical standard can be selected by specifying the name and label of the calibration kit and the
standard's serial number. Depending on the standard type, only a subset of the parameters may be used;
refer to the table of standard types.
If the specified cal kit does not exist, it is created with the specified calibration standard.
<Ch>
Channel number. This suffix is ignored because calibration kits are channel-
independent.
<std_type>
Standard type. For reflection standards, the first character denotes the gender, e.g.:
FOPEN, MOPEN: Open (f) or Open (m) standard.
The following reflection standards are supported: MOPen, FOPen, MSHort,
FSHort, OSHort, MOSHort, FOSHort, MMTCh, FFTCh, MREFLect,
FREFLect
For transmission standards, the first two characters denotes the genders on both
ends, e.g.:
FFSNetwork, MFSNetwork, MMSNetwork: Symm. network (ff), symm.
network (mf) or symm. network (mm) standard.
For a complete list of standard types refer to the table of standard types.
Parameter list
String parameters to specify the configured standard
('<Conn_Name>','<Ckit_Name>', '<Ckit_label>','<Std_No>') and
numeric parameters defining its properties. See detailed description.
Note: The following transmission standards have only 8 parameters (until <Z0>):
MMTHrough, MFTHrough, FFTHrough, MMLine, MFLine, FFLine
The following reflection and transmission standards have only 5 parameters (until
<Max_Freq>):
MSMatch, FSMatch, MMATten, MFATten, FFATten
*RST value
–
SCPI,
Command
Types
Device-specific, command or query (see examples below)
Example:
CORR:CKIT:FOP:WLAB 'N 50 Ohm','New Kit 1','123456', '',0,4000000000,0,0,50,99,-2.3,0.22,0,0,0,0,0
Define the properties of the Open (f) standard for a N 50 Ω connector type in the
calibration kit New Kit 1 labeled 123456.
CORR:CKIT:FOP:WLAB? 'N 50 Ohm','New Kit 1','123456'
Query the properties of the open (f) standard for a N 50 Ω connector type in the
active cal kit.
CORR:CKIT:FOP? 'N 50 Ohm','Test Kit'
Query the properties of the Open (f) standard for a N 50 Ω connector type in the
calibration kit.
[SENSe<Ch>:]CORRection:COLLect...
This subsystem controls the system error correction.
