'<ckit_label>'
Selects the calibration kit to be used, specifying its connector type, name, and label.
The command is suitable for connector types with arbitrary, user-defined names. For standard
connector types you can use the command
[SENSe<Ch>:]CORRection:CKIT:<conn_type>:LSELect.
<Ch>
Channel number. This suffix is ignored because calibration kits are channel-
independent.
'<conn_type>'
Connector type, e.g. a user-defined connector type (string variable)
'<ckit_name>'
String parameter containing the name of a calibration kit available on the
analyzer.
'<ckit_label>'
String parameter containing the label of a calibration kit.
*RST value
– (A *RST does not change the assignment between connector types and
calibration kits.)
SCPI, Command
Types
Device-specific, command or query (the query requires the first string parameter
only)
Example:
MMEMory:LOAD:CKIT 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\Calibration\Kits\New Kit 1 (2012-05-25).calkit'
Load the previously created cal kit file New Kit 1 (2012-
05-25).calkit from the default cal kit directory.
CORR:CKIT:LSEL 'N 50 Ohm', 'New_kit', '2012-05-25'
Assign the imported kit to the N 50 Ω connector type (assuming that the cal kit
name stored in New Kit 1 (2012-05-25).calkit reads New_kit and its
label reads 2012-05-25.
[SENSe<Ch>:]CORRection:CKIT:STANdard:LCATalog? '<ckit_name>',
'<ckit_label>'
Returns a list of all standards in a given calibration kit.
<Ch>
Channel number. This suffix is ignored because cal kits are channel-
independent.
'<ckit_name>'
Name of the cal kit. Use SENSe<Ch>:CORRection:CKIT:LCATalog? to query
cal kit names and labels.
'<ckit_label>'
String parameter containing the label of a calibration kit.
*RST value
–
SCPI, Command
Types
Device-specific, query only
Example:
See SENSe<Ch>:CORRection:CONNection:CATalog?
[SENSe<Ch>:]CORRection:CKIT:<std_type>:WLABel
'<Conn_Name>','<Ckit_Name>',
'<Ckit_label>','<Std_No>',<Min_Freq>,<Max_Freq>,<El_Length>,<Loss>,<Z0>,<C0>
