SCPI Command Reference
Operating Manual 1145.1084.12 – 30 842
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
-/-
[SENSe<Ch>:]CORRection:COLLect:AUTO:SAVE
Calculates the error terms, based on the previously acquired calibration sweeps for multiple port
assignments, saves the data and applies the calibration to the active channel <Ch>.
A complete, valid set of port assignments must have been measured
([SENSe<Ch>:]CORRection:COLLect:AUTO:ASSignment<Asg>:ACQuire) before the analyzer can
calculate the error terms; see program example.
<Ch>
Channel number
*RST value
n/a
SCPI,
Command
Types
Device-specific, no query
Example:
See
[SENSe<Ch>:]CORRection:COLLect:AUTO:ASSignment<Asg>:DEFine
[SENSe<Ch>:]CORRection:COLLect:AUTO:TYPE <cal_type>,
'<file_name>',<port_no>{,<port_no>}
Initiates a one-port, two-port, three-port or four-port automatic calibration at arbitrary analyzer and cal unit
ports. This command also selects the calibration type.
If the test setup contains a high attenuation the analyzer may fail to detect the cal unit ports connected
to each of its ports. In this case use the extended command
[SENSe<Ch>:]CORRection:COLLect:AUTO:PORTs:TYPE.
If several calibration units are connected, use SYSTem:COMMunicate:RDEVice:AKAL:ADDRess to
select a unit for the calibration.
<Ch>
Channel number
<cal_type>
FNPort – Full n-Port calibration
FOPort – Full One Port calibration
SFTPort – Separate Full Two-Port calibration
OPTPort – One Path Two Port calibration
FRTRans – Transmission normalization, bidirectional
FTRans – Transmission normalization, forward
RTRans – Transmission normalization, reverse
'<file_name>'
Name and (possibly) directory of the characterization (cal kit file) to be used for the
automatic calibration (string parameter):
