R&S ZVB - Page 856

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 841
'<file_name>'
Name and (possibly) directory of the characterization (cal kit file) to be used
for the automatic calibration (string parameter):
 If nothing is specified (empty string ' '), the factory cal kit file stored
in the active calibration unit is used.
 A NWA cal kit file name *.calkit without path denotes a specific cal
kit file stored in the active calibration unit.
 A NWA cal kit file name without path but prefixed with SD: refers to
a specific cal kit file stored on the SD card inserted at the active
calibration unit.A NWA cal kit file name *.calkit with path denotes a
specific cal kit file stored in an arbitrary directory.
<analyzer_port_no>
Port numbers of the analyzer. For an n-port automatic calibration (n = 1 to
4), n arbitrary (not necessarily consecutive) port numbers must be specified.
For a one path two port calibration (OPTPort), the first port no. denotes the
node port (fully calibrated port). The transmission normalizations are two-
port calibrations.
<cal_unit__port_no>
Port numbers of the cal unit. For an n-port automatic calibration (n = 1 to 4),
n arbitrary (not necessarily consecutive) port numbers must be specified. It
is possible to combine arbitrary (not necessarily matching) pairs of analyzer
and cal unit ports.
*RST value
–
SCPI, Command
Types
Device-specific, no query
Example:
CORR:COLL:AUTO:PORT FNPort, '', 1, 2, 2, 4, 4, 1
Perform an automatic full 3-port calibration at the analyzer test ports 1, 2,
and 4 using the calibration unit's default calibration kit file and ports 2, 4, and
1 of the cal unit.
[SENSe<Ch>:]CORRection:COLLect:AUTO:RPGRoup <Boolean>
Retain port groups during parser calibration with calibration Unit, using one of the commands
- SENSe<Ch>:CORRection:COLLect:AUTO
- SENSe<Ch>:CORRection:COLLect:AUTO:TYPE
- SENSe<Ch>:CORRection:COLLect:AUTO:PORTs
- SENSe<Ch>:CORRection:COLLect:AUTO:PORTs:TYPE
This flag has no effect for calibration types "One Path Two Port" (OPTPort) and "Separate Full Two-
Port" (SFTPort) or if calibration data are acquired using multiple port assignments (see
SENSe:CORRection:COLLect:AUTO:ASSignment:ACQUire).
The functionality is identical to the Retain Port Groups checkbox in the Calibration Settings dialog.
However, parser and GUI are not synchronized, i.e. a modification in the GUI does not affect the parser
setting and vice versa.
<Ch>
Channel number – ignored (global setting)
<Boolean>
ON | OFF
OFF: Port groups are resolved and a single system error correction for all
selected ports is created during calibration
ON: For every port group a separate system error correction is created, which is
particularly useful to calibrate port groups with frequency offset.
