R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 834
SCPI,
Command
Types
Device-specific, no query
Example:
See [SENSe<Ch>:]CORRection:COLLect:SAVE:SELected.
[SENSe<Ch>:]CORRection:COLLect:AUTO '<file_name>',<port_no>{,<port_no>}
Initiates a one-port, two-port, three-port or four-port automatic calibration at arbitrary analyzer and cal unit
ports.
If the test setup contains a high attenuation the analyzer may fail to detect the cal unit ports connected
to each of its ports. In this case use the extended command
[SENSe<Ch>:]CORRection:COLLect:AUTO:PORTs. Use
[SENSe<Ch>:]CORRection:COLLect:AUTO:TYPE if you want to specify a particular calibration type
for the automatic calibration. Use [SENSe<Ch>:]CORRection:COLLect:AUTO:CONFigure to prepare
an calibration with multiple port assignments.
If several calibration units are connected, use SYSTem:COMMunicate:RDEVice:AKAL:ADDRess to
select a unit for the calibration.
<Ch>
Channel number
'<file_name>'
Name and (possibly) directory of the characterization (cal kit file) to be used for
the automatic calibration (string parameter):
 If nothing is specified (empty string ' '), the factory cal kit file stored in the
active calibration unit is used.
 A NWA cal kit file name *.calkit without path denotes a specific cal kit file
stored in the active calibration unit.
 A NWA cal kit file name without path but prefixed with SD: refers to a
specific cal kit file stored on the SD card inserted at the active calibration
unit.
 A NWA cal kit file name *.calkit with path denotes a specific cal kit file
stored in an arbitrary directory.
<port_no>
Port numbers of the analyzer. For an n-port automatic calibration (n = 1 to 4), n
arbitrary (not necessarily consecutive) port numbers must be specified. The
analyzer automatically detects the calibration unit ports connected to each
analyzer port.
*RST value
–
SCPI,
Command
Types
Device-specific, no query
Example:
CORR:COLL:AUTO '', 1, 2, 4
Perform an automatic 3-port calibration at test ports 1, 2, and 4 using the
calibration unit's default calibration kit file and arbitrary test ports of the cal unit.
