SCPI Command Reference
Operating Manual 1145.1084.12 – 30 838
<Ch>
Channel number (ignored)
'<file_name>'
Name and (possibly) directory of the created characterization / cal
kit file (string parameter, extension *.calkit):
 If no path and directory is specified, the file is stored in the
calibration unit (see also
[SENSe<Ch>:]CORRection:COLLect:AUTO). The
factory calibration data on the unit is not overwritten. If the
file name is prefixed by SD:, the file is saved to the SD card
inserted at the calibration unit (if available/accessible).
 If a path and directory is specified, the file is stored in the
directory on the analyzer's hard disk.
The default directory (MMEMory:CDIRectory) is not used.
<characterizationMethod>
The calibration types that shall be supported with this
characterization:
FOPort – Full One Port (one port standards only)
FNPort – Full N Port (one and two port standards)
DEFault] – Default characterization method of the active cal unit
(property [CAL_PROCEDURE] > ExtCalProc set in the calu's
config.ini)
<VNA_port_i>,<CalU_port_i>
Port pair i
*RST value
–
SCPI, Command Types
Device-specific, no query
Example:
CORR:COLL:AUTO:CKIT:PORTs 'AutoCalChar.calkit',FNPort,1,1,2,2
Generate a cal kit file AutoCalChar.calkit for the active calibration
unit and store it internally.
[SENSe<Ch>:]CORRection:COLLect:AUTO:CONFigure <cal_type>, '<file_name>'
Selects a calibration type and a cal unit characterization (cal kit file) for an automatic calibration with
multiple port assignments.
<Ch>
Channel number
<cal_type>
FNPort – Full n-Port calibration
FOPort – Full One Port calibration
OPTPort – One Path Two Port calibration
The other calibration types require a single port assignment; use
[SENSe<Ch>:]CORRection:COLLect:AUTO:TYPE to perform the calibration.
*RST value
FNPort
<file_name>
Name and (possibly) directory of the characterization (cal kit file) to be used for the
automatic calibration (string parameter):
 If nothing is specified (empty string ' '), the factory cal kit file stored in the
active calibration unit is used.
 A NWA cal kit file name *.calkit without path denotes a specific cal kit file
