R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 839
stored in the active calibration unit.
 A NWA cal kit file name without path but prefixed with SD: refers to a
specific cal kit file stored on the SD card inserted at the active calibration
unit.
 A NWA cal kit file name *.calkit with path denotes a specific cal kit file stored
in an arbitrary directory.
*RST value
' ' (empty string, factory calibration)
SCPI,
Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]CORRection:COLLect:AUTO:ASSignment<Asg>:DEFine
[SENSe<Ch>:]CORRection:COLLect:AUTO:PORTs
'<file_name>',<analyzer_port_no>,<cal_unit_port_no>{,<analyzer_port_no>,<cal_u
nit_port_no>}
Selects and initiates a one-port, two-port, three-port or four-port automatic calibration at arbitrary analyzer
and calibration unit ports.
This command is necessary if the analyzer fails to detect the cal unit ports connected to each of its
ports (e.g. because of a high attenuation in the test setup). If auto-detection works you can use the simpler
command [SENSe<Ch>:]CORRection:COLLect:AUTO. Use
[SENSe<Ch>:]CORRection:COLLect:AUTO:CONFigure to prepare an calibration with multiple port
assignments.
<Ch>
Channel number
'<file_name>'
Name and (possibly) directory of the characterization (cal kit file) to be used
for the automatic calibration (string parameter):
 If nothing is specified (empty string ' '), the factory cal kit file stored
in the active calibration unit is used.
 A NWA cal kit file name *.calkit without path denotes a specific cal
kit file stored in the active calibration unit.
 A NWA cal kit file name without path but prefixed with SD: refers to
a specific cal kit file stored on the SD card inserted at the active
calibration unit.
 A NWA cal kit file name *.calkit with path denotes a specific cal kit
file stored in an arbitrary directory.
<analyzer_port_no>
Port numbers of the analyzer. For an n-port automatic calibration (n = 1 to
4), n arbitrary (not necessarily consecutive) port numbers must be specified.
<cal_unit__port_no>
Port numbers of the cal unit. For an n-port automatic calibration (n = 1 to 4),
n arbitrary (not necessarily consecutive) port numbers must be specified. It
is possible to combine arbitrary (not necessarily matching) pairs of analyzer
and cal unit ports.
*RST value
–
