R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 863
Start frequency (or CW frequency, if no frequency sweep is active)
Stop frequency (or CW frequency, if no frequency sweep is active)
Source power (or stop power, for power sweeps)
Sweep type or grid (LIN, LOG, SEGM)
Calibrated ports with receiver attenuation settings: <1st cal port>, <atten1>, <2nd cal port>,
<atten2>, <3rd cal port> ... , e.g. 1, 0.0, 2, 1.0 (calibration of ports 1 and 2, attenuation settings
0 dB and 1 dB)
Calibration type (e.g. TOSM, UOSM ...). For a complete list of returned values see table below.
Calibrated ports: comma-separated list, <1st cal port>, <2nd cal port> ... , e.g. 1, 2 (calibration
of ports 1 and 2)
List of measured Throughs with port assignment, if more than two ports are calibrated: <1st Through, 1st
port no> - <1st Through, 2nd port no>, <2nd Through, 1st port no> - <2nd Through,
2nd port no> ... , e.g. 2-3, 2-4, 3-4 (3 measured Throughs between ports 2 and 3, 2 and 4, and 3 and
4)
Reference plane shift applied to the calibration. The value represents the shift as a mechanical length in meters
as set through [SENSe<Ch>:]CORRection:COLLect:RPSHift. This is only valid for NIST Multiline TRL
calibrations
Timestamp of the calibration in 24-hour clock, returned as a comma-separated list of integers
<Year>,<Month>,<Day>,<Hour>,<Minute>,<Second>
Returned values for [SENSe<Ch>:]CORRection:DATA:PARameter<Cal>? TYPE
Refl Norm Open
Refl Norm Short
Trans Norm - Bidirectional
Trans Norm - Forward
Trans Norm - Reverse
TOM
TRM
TRM
TRL
NIST Multiline TRL
TNA
Undefined (e.g. no calibration available)
[SENSe<Ch>:]CORRection:DATA:PARameter:COUNt?
Returns the number of active system error corrections in channel no. <Ch>.
