Calibration type
Parameter in
[SENSe<Ch>:]CORRection:COLLect:METHod
Available error terms (depending on port
numbers)
reading only; the 'H21' matrix elements are
normalized to 1)
[SENSe<Ch>:]CORRection:DATA:PARameter<Cal>? [<info>]
Returns the parameters of the active system error correction(s) for channel <Ch>. If only the factory
calibration is available, an error is raised.
<Ch>
Channel number of the calibrated channel.
<Cal>
Current number of calibration, if several calibrations are assigned to the channel
(see example).
[<info>]
Optional parameter to specify the information retrieved; see table below.
Response
If <info> is omitted: Five values, corresponding to the start and stop frequency of
the calibration sweep, the number of points, the source power, and the sweep
type.
With <info> parameter: see table below
*RST value
n/a (the command generates an execution error if no system error correction is
active)
SCPI,
Command
Types
Device-specific, query only
Example:
CORR:COLL:METH:DEF 'Test1',RSHort,1
CORR:COLL:SEL SHOR,1
CORR:COLL:SAVE:SEL
Define a reflection normalization with a Short standard at port 1, perform the
calibration sweep, and apply the calibration to the active channel.
CORR:COLL:METH:DEF 'Test2',REFL,2
CORR:COLL:SEL OPEN,2
CORR:COLL:SAVE:SEL
Define a reflection normalization with an Open standard at port 2, perform the
calibration sweep, and apply the calibration to the active channel.
CORRection:DATA:PARameter1? TYPE
Query the calibration type of the first calibration. The response is RSH.
CORRection:DATA:PARameter2? TYPE
Query the calibration type of the second calibration. The response is REFL.
CORRection:DATA:PARameter:COUNt?
Query the number of active calibrations. The response is 2.
Optional parameters of [SENSe<Ch>:]CORRection:DATA:PARameter<Cal>?
Parameter
<info>
Response
– (omitted)
Start and stop frequency, no. of points, source power, sweep type
