R&S ZVB - Page 921

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 906
FREQ:IMOD:TDIS 2E6
Select a tone distance of 2 MHz.
FREQ:IMOD:ORD3 ON; ORD5 ON; ORD7 OFF; ORD9 OFF
Enable the measurement of the intermodulation products up to the 5
th
order.
...
(Perform intermodulation measurement, evaluate results.)
FREQ:IMOD:CONV OFF
Disable intermodulation measurement, switch back to normal (non
frequency-converting) mode.
[SENSe<Ch>:]FREQuency:IMODulation:ORDer<Im>[:STATe] <Boolean>
Enables or disables the measurement of the intermodulation products of order <IM order>.
<Ch>
Channel number.
<Im>
Order of IM products
Range [def. unit]
3 | 5 | 7 | 9 [–]
*RST value
–
<Boolean>
ON | OFF – enables or disables measurement
*RST value
ON (for <Im> = 3), OFF (for <Im> > 3)
SCPI, Command Types
Device-specific, command or query.
Example:
See [SENSe<Ch>:]FREQuency:IMODulation:LTONe
[SENSe<Ch>:]FREQuency:IMODulation:PEWCorr[:STATe] <Boolean>
Switches the preparation for an enhanced wave correction of an intermodulation measurement on or off.
This flag should be switched on when a source power calibration is to be performed for the receive port
(SOURce<Ch>:POWer<Pt>:CORRection:IMODulation:RPORt[:ACQuire]).
<Ch>
Channel number.
<Boolean>
ON | OFF – enables or disables preparation for an enhanced wave correction.
*RST value
OFF
SCPI,
Command
Types
Device-specific, command or query.
Example:
See
SOURce<Ch>:POWer<Pt>:CORRection:IMODulation:RPORt[:ACQuire]
