R&S ZVB - Page 970

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 955
[SENSe<Ch>:]SEGMent<Seg>[:STATe] <Boolean>
Activates or deactivates the sweep segment <Seg>. Sweep points belonging to inactive segments only
are not measured
<Ch>
Channel number
<Seg>
Sweep segment number
<Boolean>
ON | OFF - Activates or deactivates the measurement in sweep segment
<Seg>.
*RST value
ON
SCPI, Command
Types
Device-specific, command or query
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using default settings.
SEGM OFF
Disable the measurement in the created sweep segment.
[SENSe<Ch>:]SEGMent<Seg>:SWEep:DWELl <Meas. Delay>
Defines the delay time for each partial measurement in sweep segment no. <Seg> (Meas. Delay). If
coupling of the segments is switched on ([SENSe<Ch>:]SEGMent<Seg>:SWEep:DWELl:CONTrol ON)
the delay is valid for all sweep segments in the current channel.
<Ch>
Channel number
<Seg>
Sweep segment number
<Meas.
Delay>
Meas. delay before each partial measurement.
Range [def.
unit]
0 s to 2.5E+003 s. [s] Changing the delay leaves the number of points unchanged
but has an impact on the duration of the sweep
([SENSe<Ch>:]SEGMent<Seg>:SWEep:TIME).
*RST value
0 s
SCPI,
Command
Types
Device-specific, command or query. This default value corresponds to automatic
sweep time setting in manual control.
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using default settings.
SEGM:SWE:DWEL 1 MS
Set the meas. delay in segment no. 1 to 1 ms.
SEGM:DEF? Response: 300000,8000000000,51,-300,0.056559,0,10000,POS,NORM
Query the channel parameters for sweep segment 1. The response value for the
segment sweep time (olive) implicitly contains the defined meas. delay.
