Renesas M32R/ECU Series User Manual

9
DMAC
9-13
32180 Group User’s Manual (Rev.1.0)
DMA7 Channel Control Register 0 (DM7CNT0) <Address: H’0080 0438>
123456b7b0
SADSL7 DADSL7MDSEL7 TREQF7
REQSL7
TENL7 TSZSL7
00000000
<After reset: H’00>
b Bit Name Function R W
0 MDSEL7 0: Normal mode R W
DMA7 transfer mode select bit 1: Ring buffer mode
1 TREQF7 0: Transfer not requested R(Note 1)
DMA7 transfer request flag bit 1: Transfer requested
2, 3 REQSL7 00: Software start R W
DMA7 transfer request source select bit 01: SIO2_TXD (transmit buffer empty)
10: MJT(TIN2S)
11: Extended DMA7 transfer request source select
(DMA7 Channel Control Register 1)
4 TENL7 0: Disable transfer R W
DMA7 transfer enable bit 1: Enable transfer
5 TSZSL7 0: 16 bits R W
DMA7 transfer size select bit 1: 8 bits
6 SADSL7 0: Fixed R W
DMA7 source address direction select bit 1: Increment
7 DADSL7 0: Fixed R W
DMA7 destination address direction select bit 1: Increment
Note 1: Only writing "0" is effective. Writing "1" has no effect; the bit retains the value it had before the write.
DMA7 Channel Control Register 1 (DM7CNT1) <Address: H’0080 0439>
9 10 11 12 13 14 b15b8
REQESEL7
0000
0
0
0
0
<After reset: H’00>
b Bit Name Function R W
8–11 No function assigned. Fix to "0". 00
12–15 REQESEL7 0000: One DMA6 transfer completed R W
Extended DMA7 transfer request source select bit 0001: MJT(TOU0_2irq)
0010: SIO3_TXD (transmit buffer empty)
0011: Common 1) MJT (input event bus 1)
0100: Common 2) MJT (input event bus 3)
0101: Common 3) MJT (output event bus 2)
0110: Common 4) MJT (output event bus 3)
0111: Common 5) AD0 conversion completed
1000: Common 6) MJT (TIN0S)
1001: Common 7) MJT (TIO8_udf)
1010: Settings inhibited
1111: Settings inhibited
9.2 DMAC Related Registers
| |
