9.3 Functional Description of the DMAC
Table 9.3.8 DMA Transfer Request Sources and Generation Timings on DMA7
REQSL7 DMA Transfer Request Source DMA Transfer Request Generation Timing
0 0 Software start When any data is written to the DMA7 Software Request Generation Register
0 1 Serial I/O2 (transmit buffer empty) When serial I/O2 transmit buffer is empty
1 0 MJT (TIN2 input signal) When MJT TIN2 input signal is generated
1 1 Extended DMA7 transfer request The source selected by the DMA7 Channel Control Register 1 (DM7CNT1)
source selected REQESEL7 bits (see below)
REQESEL7 DMA Transfer Request Source DMA Transfer Request Generation Timing
0000 One DMA6 transfer completed When one DMA6 transfer is completed (cascade mode)
0001 MJT (TOU0_2irq) MJT TOU0_2 interrupt source
0010 Serial I/O3 (reception completed) When serial I/O3 reception is completed
0011 MJT (input event bus 1) When MJT input event bus 1 signal is generated
0100 MJT (input event bus 3) When MJT input event bus 3 signal is generated
0101 MJT (output event bus 2) When MJT output event bus 2 signal is generated
0110 MJT (output event bus 3) When MJT output event bus 3 signal is generated
0111 A-D0 conversion completed When A-D0 conversion is completed
1000 MJT (TIN0 input signal) When MJT TIN0 input signal is generated
1001 MJT (TIO8_udf) When MJT TIO8 underflow occurs
1010
| Settings inhibited –
1111
Table 9.3.9 DMA Transfer Request Sources and Generation Timings on DMA8
REQSL8 DMA Transfer Request Source DMA Transfer Request Generation Timing
0 0 Software start When any data is written to the DMA8 Software Request Generation Register
0 1 MJT (input event bus 0) When MJT input event bus 0 signal is generated
1 0 Serial I/O3 (reception completed) When serial I/O3 reception is completed
1 1 Extended DMA8 transfer request The source selected by the DMA8 Channel Control Register 1 (DM8CNT1)
source selected REQESEL8 bits (see below)
REQESEL8 DMA Transfer Request Source DMA Transfer Request Generation Timing
0000 MJT (TIN7 input signal) When MJT TIN7 input signal is generated
0001 MJT (TOU0_6irq) MJT TOU0_6 interrupt source
0010 One DMA7 transfer completed When one DMA7 transfer is completed (cascade mode)
0011 MJT (input event bus 1) When MJT input event bus 1 signal is generated
0100 MJT (input event bus 3) When MJT input event bus 3 signal is generated
0101 MJT (output event bus 2) When MJT output event bus 2 signal is generated
0110 MJT (output event bus 3) When MJT output event bus 3 signal is generated
0111 A-D0 conversion completed When A-D0 conversion is completed
1000 MJT (TIN0 input signal) When MJT TIN0 input signal is generated
1001 MJT (TIO8_udf) When MJT TIO8 underflow occurs
1010
| Settings inhibited –
1111
