Renesas M32R/ECU Series

10
10-23
MULTIJUNCTION TIMERS
10.2 Common Units of Multijunction Timers
32180 Group User’s Manual (Rev.1.0)
TIN9–11 Input Processing Control Register (TIN911CR) <Address: H’0080 0216>
b01234567891011121314b15
TIN11S TIN10S TIN9S
0
0
0
0
0
0
0
0
0
0
00
0
000
<After reset: H’0000>
b Bit Name Function R W
0–4 No function assigned. Fix to "0". 00
5–7 TIN11S 000: Disable input R W
TIN11 input processing select bit 001: Rising edge
010: Falling edge
011: Both edges
100: Low level
101: Low level
110: High level
111: High level
8 No function assigned. Fix to "0". 00
9–11 TIN10S 000: Disable input R W
TIN10 input processing select bit 001: Rising edge
010: Falling edge
011: Both edges
100: Low level
101: Low level
110: High level
111: High level
12 No function assigned. Fix to "0". 00
13–15 TIN9S 000: Disable input R W
TIN9 input processing select bit 001: Rising edge
010: Falling edge
011: Both edges
100: Low level
101: Low level
110: High level
111: High level
Note: • This register must always be accessed in halfwords.
