32180 Group User’s Manual (Rev.1.0)
13.2 CAN Module Related Registers
CAN MODULE
CAN0 Message Slot 0 Data 2 (C0MSL0DT2)
<Address: H
’0080 1108>CAN0 Message Slot 1 Data 2 (C0MSL1DT2)
<Address: H
’0080 1118>CAN0 Message Slot 2 Data 2 (C0MSL2DT2)
<Address: H
’0080 1128>CAN0 Message Slot 3 Data 2 (C0MSL3DT2)
<Address: H
’0080 1138>CAN0 Message Slot 4 Data 2 (C0MSL4DT2)
<Address: H
’0080 1148>CAN0 Message Slot 5 Data 2 (C0MSL5DT2)
<Address: H
’0080 1158>CAN0 Message Slot 6 Data 2 (C0MSL6DT2)
<Address: H
’0080 1168>CAN0 Message Slot 7 Data 2 (C0MSL7DT2)
<Address: H
’0080 1178>CAN0 Message Slot 8 Data 2 (C0MSL8DT2)
<Address: H
’0080 1188>CAN0 Message Slot 9 Data 2 (C0MSL9DT2)
<Address: H
’0080 1198>CAN0 Message Slot 10 Data 2 (C0MSL10DT2)
<Address: H
’0080 11A8>CAN0 Message Slot 11 Data 2 (C0MSL11DT2)
<Address: H
’0080 11B8>CAN0 Message Slot 12 Data 2 (C0MSL12DT2)
<Address: H
’0080 11C8>CAN0 Message Slot 13 Data 2 (C0MSL13DT2)
<Address: H
’0080 11D8>CAN0 Message Slot 14 Data 2 (C0MSL14DT2)
<Address: H
’0080 11E8>CAN0 Message Slot 15 Data 2 (C0MSL15DT2)
<Address:
H
’0080 11F8>CAN1 Message Slot 0 Data 2 (C1MSL0DT2)
<Address: H
’0080 1508>CAN1 Message Slot 1 Data 2 (C1MSL1DT2)
<Address: H
’0080 1518>CAN1 Message Slot 2 Data 2 (C1MSL2DT2)
<Address: H
’0080 1528>CAN1 Message Slot 3 Data 2 (C1MSL3DT2)
<Address: H
’0080 1538>CAN1 Message Slot 4 Data 2 (C1MSL4DT2)
<Address: H
’0080 1548>CAN1 Message Slot 5 Data 2 (C1MSL5DT2)
<Address: H
’0080 1558>CAN1 Message Slot 6 Data 2 (C1MSL6DT2)
<Address: H
’0080 1568>CAN1 Message Slot 7 Data 2 (C1MSL7DT2)
<Address: H
’0080 1578>CAN1 Message Slot 8 Data 2 (C1MSL8DT2)
<Address: H
’0080 1588>CAN1 Message Slot 9 Data 2 (C1MSL9DT2)
<Address: H
’0080 1598>CAN1 Message Slot 10 Data 2 (C1MSL10DT2)
<Address: H
’0080 15A8>CAN1 Message Slot 11 Data 2 (C1MSL11DT2)
<Address: H
’0080 15B8>CAN1 Message Slot 12 Data 2 (C1MSL12DT2)
<Address: H
’0080 15C8>CAN1 Message Slot 13 Data 2 (C1MSL13DT2)
<Address: H
’0080 15D8>CAN1 Message Slot 14 Data 2 (C1MSL14DT2)
<Address: H
’0080 15E8>CAN1 Message Slot 15 Data 2 (C1MSL15DT2)
<Address:
H
’0080 15F8>123456b7b0
C0MSL0DT2–C0MSL15DT2, C1MSL0DT2–C1MSL15DT2
????????
<After reset: Undefined>
b Bit Name Function R W
0–7 C0MSL0DT2–C0MSL15DT2, Message slot data 2 R W
C1MSL0DT2–C1MSL15DT2
These registers are the memory space for transmit and receive frames.
Note: • During a receive slot, an undefined value is written to the register if the data length of the data
frame being stored (DLC value) is equal to or less than 2.
To Next Page
