32180 Group User’s Manual (Rev.1.0)
CAN MODULE
13.2 CAN Module Related Registers
CAN0 Message Slot 0 Data 3 (C0MSL0DT3)
<Address: H
’0080 1109>CAN0 Message Slot 1 Data 3 (C0MSL1DT3)
<Address: H
’0080 1119>CAN0 Message Slot 2 Data 3 (C0MSL2DT3)
<Address: H
’0080 1129>CAN0 Message Slot 3 Data 3 (C0MSL3DT3)
<Address: H
’0080 1139>CAN0 Message Slot 4 Data 3 (C0MSL4DT3)
<Address: H
’0080 1149>CAN0 Message Slot 5 Data 3 (C0MSL5DT3)
<Address: H
’0080 1159>CAN0 Message Slot 6 Data 3 (C0MSL6DT3)
<Address: H
’0080 1169>CAN0 Message Slot 7 Data 3 (C0MSL7DT3)
<Address: H
’0080 1179>CAN0 Message Slot 8 Data 3 (C0MSL8DT3)
<Address: H
’0080 1189>CAN0 Message Slot 9 Data 3 (C0MSL9DT3)
<Address: H
’0080 1199>CAN0 Message Slot 10 Data 3 (C0MSL10DT3)
<Address: H
’0080 11A9>CAN0 Message Slot 11 Data 3 (C0MSL11DT3)
<Address: H
’0080 11B9>CAN0 Message Slot 12 Data 3 (C0MSL12DT3)
<Address: H
’0080 11C9>CAN0 Message Slot 13 Data 3 (C0MSL13DT3)
<Address: H
’0080 11D9>CAN0 Message Slot 14 Data 3 (C0MSL14DT3)
<Address: H
’0080 11E9>CAN0 Message Slot 15 Data 3 (C0MSL15DT3)
<Address:
H
’0080 11F9>CAN1 Message Slot 0 Data 3 (C1MSL0DT3)
<Address: H
’0080 1509>CAN1 Message Slot 1 Data 3 (C1MSL1DT3)
<Address: H
’0080 1519>CAN1 Message Slot 2 Data 3 (C1MSL2DT3)
<Address: H
’0080 1529>CAN1 Message Slot 3 Data 3 (C1MSL3DT3)
<Address: H
’0080 1539>CAN1 Message Slot 4 Data 3 (C1MSL4DT3)
<Address: H
’0080 1549>CAN1 Message Slot 5 Data 3 (C1MSL5DT3)
<Address: H
’0080 1559>CAN1 Message Slot 6 Data 3 (C1MSL6DT3)
<Address: H
’0080 1569>CAN1 Message Slot 7 Data 3 (C1MSL7DT3)
<Address: H
’0080 1579>CAN1 Message Slot 8 Data 3 (C1MSL8DT3)
<Address: H
’0080 1589>CAN1 Message Slot 9 Data 3 (C1MSL9DT3)
<Address: H
’0080 1599>CAN1 Message Slot 10 Data 3 (C1MSL10DT3)
<Address: H
’0080 15A9>CAN1 Message Slot 11 Data 3 (C1MSL11DT3)
<Address: H
’0080 15B9>CAN1 Message Slot 12 Data 3 (C1MSL12DT3)
<Address: H
’0080 15C9>CAN1 Message Slot 13 Data 3 (C1MSL13DT3)
<Address: H
’0080 15D9>CAN1 Message Slot 14 Data 3 (C1MSL14DT3)
<Address: H
’0080 15E9>CAN1 Message Slot 15 Data 3 (C1MSL15DT3)
<Address:
H
’0080 15F9>9 10 11 12 13 14 b15b8
C0MSL0DT3–C0MSL15DT3, C1MSL0DT3–C1MSL15DT3
????????
<After reset: Undefined>
b Bit Name Function R W
8–15 C0MSL0DT3–C0MSL15DT3, Message slot data 3 R W
C1MSL0DT3–C1MSL15DT3
These registers are the memory space for transmit and receive frames.
Note: • During a receive slot, an undefined value is written to the register if the data length of the data
frame being stored (DLC value) is equal to or less than 3.
To Next Page
