13-67
13
32180 Group User’s Manual (Rev.1.0)
13.2 CAN Module Related Registers
CAN MODULE
CAN0 Message Slot 0 Data 4 (C0MSL0DT4)
<Address: H
’0080 110A>CAN0 Message Slot 1 Data 4 (C0MSL1DT4)
<Address: H
’0080 111A>CAN0 Message Slot 2 Data 4 (C0MSL2DT4)
<Address: H
’0080 112A>CAN0 Message Slot 3 Data 4 (C0MSL3DT4)
<Address: H
’0080 113A>CAN0 Message Slot 4 Data 4 (C0MSL4DT4)
<Address: H
’0080 114A>CAN0 Message Slot 5 Data 4 (C0MSL5DT4)
<Address: H
’0080 115A>CAN0 Message Slot 6 Data 4 (C0MSL6DT4)
<Address: H
’0080 116A>CAN0 Message Slot 7 Data 4 (C0MSL7DT4)
<Address: H
’0080 117A>CAN0 Message Slot 8 Data 4 (C0MSL8DT4)
<Address: H
’0080 118A>CAN0 Message Slot 9 Data 4 (C0MSL9DT4)
<Address: H
’0080 119A>CAN0 Message Slot 10 Data 4 (C0MSL10DT4)
<Address: H
’0080 11AA>CAN0 Message Slot 11 Data 4 (C0MSL11DT4)
<Address: H
’0080 11BA>CAN0 Message Slot 12 Data 4 (C0MSL12DT4)
<Address: H
’0080 11CA>CAN0 Message Slot 13 Data 4 (C0MSL13DT4)
<Address: H
’0080 11DA>CAN0 Message Slot 14 Data 4 (C0MSL14DT4)
<Address: H
’0080 11EA>CAN0 Message Slot 15 Data 4 (C0MSL15DT4)
<Address: H
’0080 11FA>CAN1 Message Slot 0 Data 4 (C1MSL0DT4)
<Address: H
’0080 150A>CAN1 Message Slot 1 Data 4 (C1MSL1DT4)
<Address: H
’0080 151A>CAN1 Message Slot 2 Data 4 (C1MSL2DT4)
<Address: H
’0080 152A>CAN1 Message Slot 3 Data 4 (C1MSL3DT4)
<Address: H
’0080 153A>CAN1 Message Slot 4 Data 4 (C1MSL4DT4)
<Address: H
’0080 154A>CAN1 Message Slot 5 Data 4 (C1MSL5DT4)
<Address: H
’0080 155A>CAN1 Message Slot 6 Data 4 (C1MSL6DT4)
<Address: H
’0080 156A>CAN1 Message Slot 7 Data 4 (C1MSL7DT4)
<Address: H
’0080 157A>CAN1 Message Slot 8 Data 4 (C1MSL8DT4)
<Address: H
’0080 158A>CAN1 Message Slot 9 Data 4 (C1MSL9DT4)
<Address: H
’0080 159A>CAN1 Message Slot 10 Data 4 (C1MSL10DT4)
<Address: H
’0080 15AA>CAN1 Message Slot 11 Data 4 (C1MSL11DT4)
<Address: H
’0080 15BA>CAN1 Message Slot 12 Data 4 (C1MSL12DT4)
<Address: H
’0080 15CA>CAN1 Message Slot 13 Data 4 (C1MSL13DT4)
<Address: H
’0080 15DA>CAN1 Message Slot 14 Data 4 (C1MSL14DT4)
<Address: H
’0080 15EA>CAN1 Message Slot 15 Data 4 (C1MSL15DT4)
<Address: H
’0080 15FA>123456b7b0
C0MSL0DT4–C0MSL15DT4, C1MSL0DT4–C1MSL15DT4
????????
<After reset: Undefined>
b Bit Name Function R W
0–7 C0MSL0DT4–C0MSL15DT4, Message slot data 4 R W
C1MSL0DT4–C1MSL15DT4
These registers are the memory space for transmit and receive frames.
Note: • During a receive slot, an undefined value is written to the register if the data length of the data
frame being stored (DLC value) is equal to or less than 4.
To Next Page
