32180 Group User’s Manual (Rev.1.0)
13.2 CAN Module Related Registers
CAN MODULE
CAN0 Message Slot 0 Data 6 (C0MSL0DT6)
<Address: H
’0080 110C>CAN0 Message Slot 1 Data 6 (C0MSL1DT6)
<Address: H
’0080 111C>CAN0 Message Slot 2 Data 6 (C0MSL2DT6)
<Address: H
’0080 112C>CAN0 Message Slot 3 Data 6 (C0MSL3DT6)
<Address: H
’0080 113C>CAN0 Message Slot 4 Data 6 (C0MSL4DT6)
<Address: H
’0080 114C>CAN0 Message Slot 5 Data 6 (C0MSL5DT6)
<Address: H
’0080 115C>CAN0 Message Slot 6 Data 6 (C0MSL6DT6)
<Address: H
’0080 116C>CAN0 Message Slot 7 Data 6 (C0MSL7DT6)
<Address: H
’0080 117C>CAN0 Message Slot 8 Data 6 (C0MSL8DT6)
<Address: H
’0080 118C>CAN0 Message Slot 9 Data 6 (C0MSL9DT6)
<Address: H
’0080 119C>CAN0 Message Slot 10 Data 6 (C0MSL10DT6)
<Address: H
’0080 11AC>CAN0 Message Slot 11 Data 6 (C0MSL11DT6)
<Address: H
’0080 11BC>CAN0 Message Slot 12 Data 6 (C0MSL12DT6)
<Address: H
’0080 11CC>CAN0 Message Slot 13 Data 6 (C0MSL13DT6)
<Address: H
’0080 11DC>CAN0 Message Slot 14 Data 6 (C0MSL14DT6)
<Address: H
’0080 11EC>CAN0 Message Slot 15 Data 6 (C0MSL15DT6)
<Address: H
’0080 11FC>CAN1 Message Slot 0 Data 6 (C1MSL0DT6)
<Address: H
’0080 150C>CAN1 Message Slot 1 Data 6 (C1MSL1DT6)
<Address: H
’0080 151C>CAN1 Message Slot 2 Data 6 (C1MSL2DT6)
<Address: H
’0080 152C>CAN1 Message Slot 3 Data 6 (C1MSL3DT6)
<Address: H
’0080 153C>CAN1 Message Slot 4 Data 6 (C1MSL4DT6)
<Address: H
’0080 154C>CAN1 Message Slot 5 Data 6 (C1MSL5DT6)
<Address: H
’0080 155C>CAN1 Message Slot 6 Data 6 (C1MSL6DT6)
<Address: H
’0080 156C>CAN1 Message Slot 7 Data 6 (C1MSL7DT6)
<Address: H
’0080 157C>CAN1 Message Slot 8 Data 6 (C1MSL8DT6)
<Address: H
’0080 158C>CAN1 Message Slot 9 Data 6 (C1MSL9DT6)
<Address: H
’0080 159C>CAN1 Message Slot 10 Data 6 (C1MSL10DT6)
<Address: H
’0080 15AC>CAN1 Message Slot 11 Data 6 (C1MSL11DT6)
<Address: H
’0080 15BC>CAN1 Message Slot 12 Data 6 (C1MSL12DT6)
<Address: H
’0080 15CC>CAN1 Message Slot 13 Data 6 (C1MSL13DT6)
<Address: H
’0080 15DC>CAN1 Message Slot 14 Data 6 (C1MSL14DT6)
<Address: H
’0080 15EC>CAN1 Message Slot 15 Data 6 (C1MSL15DT6)
<Address: H
’0080 15FC>123456b7b0
C0MSL0DT6–C0MSL15DT6, C1MSL0DT6–C1MSL15DT6
????????
<After reset: Undefined>
b Bit Name Function R W
0–7 C0MSL0DT6–C0MSL15DT6, Message slot data 6 R W
C1MSL0DT6–C1MSL15DT6
These registers are the memory space for transmit and receive frames.
Note: • During a receive slot, an undefined value is written to the register if the data length of the data
frame being stored (DLC value) is equal to or less than 6.
