ATC: ASCII time code reference
USER: User provided time
LOCL: Local reference (synced to itself)
INIT: NTP on server/peer is initializing
STEP: NTP on server/peer is performing initial synchronization step
and restarting
AUTH STATUS: Indicates if the selected reference is using MD5 authen-
tication. “None” indicates authentication not being used.
LAST: The number of seconds that have expired since this reference was
last polled for its time.
POLL: The polling interval, i.e. how often VersaSync is polling this NTP ref-
erence for its time.
DELAY (ms): The measured one-way delay between VersaSync and its
selected reference.
NTP Servers: Adding, Configuring, Removing
To add, configure, or remove an NTP Server:
1. Navigate to MANAGEMENT > NETWORK: NTP Setup.
2.8 Configuring Network Settings
CHAPTER 2 • VersaSync User Manual Rev. 12
