1PPS Phase Error—An internal measurement (in nanoseconds) of the
internal 1PPSs’ phase error with respect to the selected input reference (if
the input reference has excessive jitter, phase error will be higher)
10MHz Frequency Error—An internal estimated calculation (in Hertz) of the
internal oscillator’s frequency error, based on the phase accuracy error at
the beginning and end of a frequency measurement window (the length of
this window will vary depending upon the type of oscillator installed and
the oscillator adjustment algorithm).
Events panel
The Events panel in the bottom-left corner of the HOME screen is a log of Ver-
saSync’s recent activity. It updates in real time.
Note: If you know the individual reference or output whose status
you wish to see, you can access the Status window of that reference
or output directly through the INTERFACES > REFERENCES or
INTERFACES > OUTPUTS drop-down menu.
Status Monitoring via the System Monitor Screen
To display status information pertaining mainly to VersaSync's current hardware
status, navigate to TOOLS > SYSTEM > System Monitor.
The information provided on the System Monitor Screen is subdivided into three
panels:
System Status panel
This is identical with the HOME screen "System Status panel" on page268.
Disk Status panel
This panel displays:
Total: [MB]
Used: [MB]
Free: [MB]
Percent: [%]
The last item refers to system storage. If you need to update the System Soft-
ware, and this number is 70% or higher, it is recommended to clear logs and stats
in order to free up memory space. (Navigate to TOOLS > SYSTEM:
270
