SATO CL4NX Plus User Manual

45
Show video fromNo. Guidance Videos
Error screen Startup Guide [Information]
Menu
15 Fan-fold media
replacement (Cutter)
Possible - Possible
16 Ribbon replacement Possible - Possible
17 Print head replacement - - Possible
18 Platen roller replacement - - Possible
19 Cleaning - - Possible
Playing the Guidance Video from the Error Screen
Play the guidance video from the error screen and resolve the error by following the procedure of the
video.
1.
On the error screen, press the button to play the guidance video.
If there are more videos to choose from, press the arrow buttons to select the guidance video, and
then press the button. The guidance video starts.
2. Follow the procedures to resolve the error according to the guidance video.
Getting Access to the Guidance Video in Online Mode
When in the Online mode, play the guidance video according to the following procedure.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
