SATO CL4NX Plus User Manual

743
Product Specifications
Specifications
Hardware
Dimensions and Weight
Item CL4NX Plus
Width 271 mm (10.67") (Excludes projection)
Height 321 mm (12.64") (Excludes projection)
Depth 457 mm (18.00") (Excludes projection)
Weight Approximately 15.1 kg (33.28 lbs.) (Excludes media, ribbon and options)
Power Supply
Item CL4NX Plus
Input Voltage AC 100 - 240 V ±10% (Full-range)
Frequency 50 / 60 Hz
Power Consumption
At peak
180 W / 190 VA (Print ratio 30%)
Standby
20 W / 40 VA
Processing
Item CL4NX Plus
Flash ROM
CPU1
2 GB
CPU2
4 MB
SDRAM
CPU1
256 MB

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
