Loading the Media with the Optional Dispenser Unit and Liner Discharge Rewinder
The below topic describes the procedure to dispense the label and rewind the liner in the product.
• The maximum diameter of the liner that can be rewound in the product is φ120 mm
(4.72").
• The routing path of the media is shown in the below picture.
Label
Liner
1. Open the top cover (1).
