Configuring Optional Barcode Check Function
Basic Specifications of the Barcode Check Function
The barcode check function does a reading check of a barcode printed by this product to prevent the
distribution of labels with defective barcodes. You can use this function by installing the supported
barcode checkers to the product.
The basic specifications of the barcode check function are as follows:
Item Specification
Supported Barcode
Checkers
• IDEC/DATALOGIC (USB connection)
◦ WB1F-100S1S (for 1D barcodes)
◦ GFS4170 (for 1D barcodes)
◦ GFS4470 (for 1D barcodes/2D codes)
• KEYENCE (RE-232C connection)
◦ BL-1301 (for 1D barcodes)
◦ SR-710 (for 1D barcodes/2D codes)
Refer to the manual of the barcode checker for its settings and
supported barcodes.
Supported Commands SBPL/SZPL/SIPL/STCL/SDPL/SEPL
• AEP is not supported.
Supported Print Modes Continuous/Cutter/Cut & Print/Dispenser/Linerless
• Not available in Tear-Off mode.
• The Void Print function is not available in Dispenser/
Linerless mode.
Print Speed/Print
Darkness
The optimal print speed and print darkness for secure reading vary
depending on various conditions, such as the barcode type and label
layout. Be sure to perform a test read carefully and determine the
settings.
Printable Area
(Barcode Readable Area)
Same as the product specifications. However, there are following
restrictions:
