[HEX-Dump]
474
Offset
Set the stop position of the media.
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
Resolution CL4NX Plus
203 dpi
(1 dot = 0.125 mm (0.0049"))
-30 to 0 to 30 dots
305 dpi
(1 dot = 0.083 mm (0.0033"))
-45 to 0 to 45 dots
609 dpi
(1 dot = 0.042 mm (0.0017"))
-90 to 0 to 90 dots
When you decrease the setting value, the stop position moves in the feed direction (toward the
front part of the media).
When you increase the setting value, the stop position moves opposite the feed direction (toward
the end part of the media).
Darkness Adjust
Fine tune the print darkness of the head check print.
0 is the lightest and 99 is the darkest.
• The value of [Label Length], [Pitch], [Offset] and [Darkness Adjust] set in the [Head
Check] menu will be reflected to the same item settings in the [Factory] menu,
[Configure List] menu, [Configure QR] menu and [Paper Sensor] menu.
[HEX-Dump]
Save the hex dump print data or dump data from the receive buffer to the USB memory.
The setting items are as follows:
To Next Page
